Input Parameter
Output Parameter
● Input Voltage
AC 120V
● Lamp Power
1000W
● Working Current
7.80A
● 100% Lamp Power
● Power
1040W
● Output Frequency
200Hz
● Dimming
NA
● Lamp Current Harmonics
<1.5%
● Frequency
50/60Hz
● Fire Voltage
3~5KV
● THD
<10%
● Max Fire Distance
13M
● PF
>0.97
● Short-circuit Time
4Min
● Voltage Range
AC 106~135V
● Trigger Failure Automatically Closes
30Min.
Physical Parameter
● Dimension（L×W×H）
254×168×84.5mm
● Input Power Cord
6 ft*3C*316*600V
● Weight
3.80kg / 8.38LB
● House Material
Aluminium
● Working Temperature
-25℃~+50℃ / -13℉~122℉
● Tc
Tc +80℃ /176℉
● IP Level
IP65
● Noise Level
Rated ‘A’
● Thermal Protection Level
P
