Input Parameter
Output Parameter
● Input Voltage
AC 347V
● Lamp Power
315W
● Working Current
1.0A
● 100% Lamp Power
357W
● Power
345W
● Output Frequency
120Hz
● Dimming
50%,60%,70%,80%,90%,100%
● Lamp Current Harmonics
<1.5
● Frequency
50/60Hz
● Fire Voltage
>3KV
● THD
<10%
● Max Fire Distance
13M
● PF
>0.97
● Short-circuit Time
5Min
● Voltage Range
AC 312-381V
● Trigger Failure Automatically Closes
25Min.
● Dimension（L×W×H）
196×132×73 mm
● Input Power Cord
8 ft*3C*316*600V
● Weight
1.96kg / 4.32IB
● House Material
Aluminium
● Working Temperature
-25℃~+50℃ / -13℉~122℉
● Tc
Tc +80℃ /176℉
● IP Level
IP65
● Noise Level
Rated ‘A’
● Thermal Protection Level
P
